25 mm (1") Pro-Flo® SHIFT Series Bolted Metal AODD Pump
PS220/PS230

AIR INLET

1/2" FNPT

LIQUID INLET

25 mm (1")

LIQUID DISCHARGE

25 mm (1")

CONNECTION TYPE

NPT/BSPT (Threaded)

DIN/ANSI (Flanged)

MAX SUCTION LIFT CAPABILITY

Rubber – 6.9 m (22.7') Dry, 9.0 m (29.5') Wet

TPE – 5.9 m (19.3') Dry, 9.0 m (29.5') Wet

Full-Stroke PTFE – 5.2 m (17.0') Dry, 9.0 m (29.5') Wet

MAX FLOW RATE

Rubber – 204 lpm (54 gpm)

TPE – 212 lpm (56 gpm)

Full-Stroke PTFE – 197 lpm (52 gpm)

MAX PRESSURE

8.6 bar (125 psi)

MAX DIAMETER SOLIDS

6.4 mm (1/4")

DISPLACEMENT PER STROKE *

Rubber – 0.30 L (0.08 gal)

TPE – 0.26 L (0.07 gal)

Full-Stroke PTFE – 0.30 L (0.08 gal)

^* 1 cycle = 2 strokes
